| ブランド名: | BOE |
| モデル番号: | DV150X0M-N10 |
| MOQ: | 10個 |
| 価格: | negotiable |
| 支払条件: | T/T、W、ウェスタンユニオン、マネーグラム |
| 供給能力: | 週に3000pcs |
| Brand | BOE | Model | DV150X0M-N10 1 Compatible |
|---|---|---|---|
| Diagonal Size | 15.0 inch | Type | a-Si TFT-LCD, LCM |
| Pixel Number | 1024(RGB)×768, 4:3, XGA | Pixel Format | RGB Vertical Stripe |
| Active Area | 304.128(H)×228.096(V) mm | Physical Size | 326.5(H)×253.5(V)×10(D) mm |
| Mass | 930g | Surface Coating | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 350 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry | Response Time | 30 (Typ.)(Tr+Td) ms |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Operating Mode | ADS, Normally Black, Transmissive |
| Support Color | 16.7M, 72% NTSC | Designed For | Industrial, Digital Signage |
| Power Usage | 10.8/13.2W (Typ./Max.) | Light Source | 12S4P WLED, 50K hrs, With LED Driver |
| Frame Rate | 60Hz | Touch Panel | Without |
| Interface Type | LVDS (1 ch, 8-bit), 20 pins Connector | ||
| Power Supply | 3.3V (Typ.) | ||
| Environment | Operating Temperature -20°C to 70°C, Storage Temperature -20°C to 70°C | ||
