| ブランド名: | AUO |
| モデル番号: | M270DTN01.0 |
| MOQ: | 10個 |
| 価格: | negotiable |
| 支払条件: | ウエスタンユニオン、マネーグラム、t/t |
| 供給能力: | 1週あたりの20000pcs |
| Panel Brand | AUO |
|---|---|
| Panel Size | 27.0" |
| Resolution | 2560(RGB)×1440 (Quad-HD, 108 PPI) |
| Display Area | 596.736(W)×335.664(H) mm |
| Outline Size | 608.8(W)×354.66(H)×15.08(D) mm |
| Brightness | 350 cd/m² (Typical) |
| Viewing Angle | 85/85/80/80 (Typical, CR≥10) |
| Display Colors | 16.7M, 98% sRGB |
| Refresh Rate | 144Hz |
| Weight | 2.39 kg (Typical) |
| Panel Model | M270DTN01.3 |
|---|---|
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Surface Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typical) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 3.5/1.5 (Typical)(Tr/Td) |
| Backlight System | 18S4P WLED, 30K hours, Without Driver |
| Touch Screen | Without |
| Signal Interface | LVDS (8 ch, 8-bit), 130 pins Connector |
|---|---|
| Input Voltage | 12.0V (Typical) |
| Operating Temperature | 0 ~ 50 °C |
| Storage Temperature | -20 ~ 60 °C |
AU Optronics Corp. M270DTN01.0 is a 27.0-inch diagonal a-Si TFT-LCD display panel with integrated WLED backlight system. This panel operates within 0~50°C temperature range and withstands vibrations up to 1.5G (14.7 m/s²).
Ideal for desktop monitors and gaming applications where high refresh rates and Quad-HD resolution are essential.
